50Hz LG LCD Video Wall Display 49Inch 3.5mm Bezel 3x3 FHD Resolution
55 Inch 3x3 video wall with narrow bezel original tv lcd display panel
Specification
| Product size table |
| Panel size | Bilateral seam | Panel Length | Panel Width | Panel Thickness | Panel Brand | Model No. |
| 46inch | 1.7mm | 1020.02mm | 574.61mm | 120.54mm | Samsung | LTI460HN15 |
| 46inch | 3.5mm | 1021.98mm | 576.57mm | 121.7mm | Samsung | LTI460HN11 |
| 46inch | 5.5mm | 1023.98mm | 578.57mm | 133mm | Samsung | LTI460HN09 |
| 49inch | 1.8mm | 1077.58mm | 607.8mm | 113.7mm | LG | LD490DUN-TJB2 |
| 49inch | 3.5mm | 1077.58mm | 607.8mm | 113.7mm | LG | LD490DUN-THC4 |
| 55inch | 1.8mm | 1213.5mm | 684.3mm | 110mm | LG | LD550DUN-THB8 |
| 55inch | 3.5mm | 1213.5mm | 684.30mm | 110mm | Samsung | LTI550HN11 |
- After-sales Service Provided:
-
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
- Input Voltage:
-
AC100V~240V
- Type:
-
TFT
- Viewing Angle:
-
178°
- Brightness:
-
450cd/m2
- Contrast Ratio:
-
3500:1
- Response Time:
-
<=6ms
- Size:
-
55 inch video wall
- Bezel:
-
5.3mm
- DVI:
-
1
- VGA:
-
1
- YPbPr:
-
1(BNCx3)
- S-video:
-
1(BNCx2)
- Composite Video Input/(AV):
-
3(BNCx3)
- Composite Video Output:
-
2(BNCx2)
- weight:
-
22kg
Features
1.Full hardware architecture, professional splicing chip design without CPU and operating system
2.Multi-line parallel processing with powerful processing functions;
3.Integrated multiple video signal sources
4.RS232 serial port remote control; support two RS232 loop-outs
5.Can open the underlying communication protocol, which is convenient for users to flexibly adopt third-party central control, system or self-programmed software to construct a large screen engineering system
6.Embedded firmware intelligent upgrade system.
7.Narrow border full metal frame design
8.Fully silent industrial fan with automatic temperature switch
9.With 3D noise reduction, 3D filtering, 3D deinterlacing
10.Comes with a large screen splicing piece, a healthy splicing, easy to use
11.With energy saving, environmental protection, no radiation, support 7 * 24 hours of uninterrupted work, adapt to a variety of working environments that need to be turned on for a long time
12.Uniform brightness, stable image, no flicker, no distortion
13.Applicable to: commercial institutions, large shopping malls, specialty stores, franchise stores, hypermarkets, star hotels, restaurants, travel agencies, drug stores, etc.
